Gradle Server Start

Server的启动主要是进行初始化和环境的准备

主要可以分为如下几个过程

  1. Bootstrap：启动进程，设置ClassLoader
  2. Init：初始化成员，初始化Socket
  3. Wait：进程keep-alive，防止main线程死亡，休眠等待。

Bootstrap

前面分析到了Gradle会通过ProcessBuilder开启一个Deamon进程

并调用shell

1
2
java -cp *gradle-launcher-7.6.jar
org.gradle.launcher.daemon.bootstrap.GradleDaemon

BootStrap

和Client启动类似

1
2
3
4
5
public class GradleDaemon {
    public static void main(String[] args) {
        ProcessBootstrap.run("org.gradle.launcher.daemon.bootstrap.DaemonMain", args);
    }
}

设置ClassLoader

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
public static void run(String mainClassName, String[] args) {
        try {
            runNoExit(mainClassName, args);
            System.exit(0);
        } catch (Throwable throwable) {
            throwable.printStackTrace();
            System.exit(1);
        }
    }

    private static void runNoExit(String mainClassName, String[] args) throws Exception { /* 配置ClassLoader */
        ClassPathRegistry classPathRegistry = new DefaultClassPathRegistry(new DefaultClassPathProvider(new DefaultModuleRegistry(CurrentGradleInstallation.get())));
        ClassLoaderFactory classLoaderFactory = new DefaultClassLoaderFactory();
        ClassPath antClasspath = classPathRegistry.getClassPath("ANT");
        ClassPath runtimeClasspath = classPathRegistry.getClassPath("GRADLE_RUNTIME");
        ClassLoader antClassLoader = classLoaderFactory.createIsolatedClassLoader("ant-loader", antClasspath);
        ClassLoader runtimeClassLoader = new VisitableURLClassLoader("ant-and-gradle-loader", antClassLoader, runtimeClasspath);

        ClassLoader oldClassLoader = Thread.currentThread().getContextClassLoader();
        Thread.currentThread().setContextClassLoader(runtimeClassLoader);

        try {
            Class<?> mainClass = runtimeClassLoader.loadClass(mainClassName);
            Object entryPoint = mainClass.getConstructor().newInstance();
            Method mainMethod = mainClass.getMethod("run", String[].class);
            mainMethod.invoke(entryPoint, new Object[]{args});
        } finally {
            Thread.currentThread().setContextClassLoader(oldClassLoader);

            ClassLoaderUtils.tryClose(runtimeClassLoader);
            ClassLoaderUtils.tryClose(antClassLoader);
        }
    }

DaemonMain

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
protected void doAction(String[] args, ExecutionListener listener) {
       // check,判断args
       if (args.length != 1) {
           invalidArgs("Following arguments are required: <gradle-version>");
       }

       // 从stdin读取
       List<String> startupOpts;
       File gradleHomeDir;
       File daemonBaseDir;
       int idleTimeoutMs;
       int periodicCheckIntervalMs;
       boolean singleUse;
       String daemonUid;
       DaemonParameters.Priority priority;
       List<File> additionalClassPath;
	// 读取配置参数
       KryoBackedDecoder decoder = new KryoBackedDecoder(new EncodedStream.EncodedInput(System.in));
       try {
           gradleHomeDir = new File(decoder.readString());
           daemonBaseDir = new File(decoder.readString());
           idleTimeoutMs = decoder.readSmallInt();
           periodicCheckIntervalMs = decoder.readSmallInt();
           singleUse = decoder.readBoolean();
           daemonUid = decoder.readString();
           priority = DaemonParameters.Priority.values()[decoder.readSmallInt()];
           int argCount = decoder.readSmallInt();
           startupOpts = new ArrayList<String>(argCount);
           for (int i = 0; i < argCount; i++) {
               startupOpts.add(decoder.readString());
           }
           int additionalClassPathLength = decoder.readSmallInt();
           additionalClassPath = new ArrayList<File>(additionalClassPathLength);
           for (int i = 0; i < additionalClassPathLength; i++) {
               additionalClassPath.add(new File(decoder.readString()));
           }
       } catch (EOFException e) {
           throw new UncheckedIOException(e);
       }
	// 初始化service
       NativeServices.initializeOnDaemon(gradleHomeDir);
       DaemonServerConfiguration parameters = new DefaultDaemonServerConfiguration(daemonUid, daemonBaseDir, idleTimeoutMs, periodicCheckIntervalMs, singleUse, priority, startupOpts);
       LoggingServiceRegistry loggingRegistry = LoggingServiceRegistry.newCommandLineProcessLogging();
       LoggingManagerInternal loggingManager = loggingRegistry.newInstance(LoggingManagerInternal.class);

       DaemonServices daemonServices = new DaemonServices(parameters, loggingRegistry, loggingManager, DefaultClassPath.of(additionalClassPath));
       File daemonLog = daemonServices.getDaemonLogFile();

       // Any logging prior to this point will not end up in the daemon log file.
       initialiseLogging(loggingManager, daemonLog);

       // Detach the process from the parent terminal/console
       ProcessEnvironment processEnvironment = daemonServices.get(ProcessEnvironment.class);
       processEnvironment.maybeDetachProcess();

       LOGGER.debug("Assuming the daemon was started with following jvm opts: {}", startupOpts);
	// 开启后台daemon线程
       Daemon daemon = daemonServices.get(Daemon.class);
       daemon.start();

       try {
           DaemonContext daemonContext = daemonServices.get(DaemonContext.class);
           Long pid = daemonContext.getPid();
           daemonStarted(pid, daemon.getUid(), daemon.getAddress(), daemonLog);
           DaemonExpirationStrategy expirationStrategy = daemonServices.get(MasterExpirationStrategy.class);
           daemon.stopOnExpiration(expirationStrategy, parameters.getPeriodicCheckIntervalMs());
       } finally {
           daemon.stop();
           // TODO: Stop all daemon services
           CompositeStoppable.stoppable(daemonServices.get(GradleUserHomeScopeServiceRegistry.class)).stop();
       }
   }

Init

Daemon

初始化监听 & 初始化服务器连接

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
public void start() {
    LOGGER.info("start() called on daemon - {}", daemonContext);
    lifecycleLock.lock();
    try {
        if (stateCoordinator != null) {
            throw new IllegalStateException("cannot start daemon as it is already running");
        }

        // Generate an authentication token, which must be provided by the client in any requests it makes
        SecureRandom secureRandom = new SecureRandom();
        byte[] token = new byte[16];
        secureRandom.nextBytes(token);

        registryUpdater = new DaemonRegistryUpdater(daemonRegistry, daemonContext, token);

        ShutdownHooks.addShutdownHook(new Runnable() {
            @Override
            public void run() {
                try {
                    daemonRegistry.remove(connectorAddress);
                } catch (Exception e) {
                    LOGGER.debug("VM shutdown hook was unable to remove the daemon address from the registry. It will be cleaned up later.", e);
                }
            }
        });

        Runnable onStartCommand = new Runnable() {
            @Override
            public void run() {
                registryUpdater.onStartActivity();
            }
        };

        Runnable onFinishCommand = new Runnable() {
            @Override
            public void run() {
                registryUpdater.onCompleteActivity();
            }
        };

        Runnable onCancelCommand = new Runnable() {
            @Override
            public void run() {
                registryUpdater.onCancel();
            }
        };

        // Start the pipeline in reverse order:
        // 1. mark daemon as running
        // 2. start handling incoming commands
        // 3. start accepting incoming connections
        // 4. advertise presence in registry

        stateCoordinator = new DaemonStateCoordinator(executorFactory, onStartCommand, onFinishCommand, onCancelCommand);
        connectionHandler = new DefaultIncomingConnectionHandler(commandExecuter, daemonContext, stateCoordinator, executorFactory, token);
        Runnable connectionErrorHandler = new Runnable() {
            @Override
            public void run() {
                stateCoordinator.stop();
            }
        };
        connectorAddress = connector.start(connectionHandler, connectionErrorHandler);
        LOGGER.debug("Daemon starting at: {}, with address: {}", new Date(), connectorAddress);
        registryUpdater.onStart(connectorAddress);
    } finally {
        lifecycleLock.unlock();
    }

    LOGGER.lifecycle(DaemonMessages.PROCESS_STARTED);
}

Connector

注册了一个connect监听

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
public class DaemonTcpServerConnector implements DaemonServerConnector {
    // ......
     public Address start(final IncomingConnectionHandler handler, final Runnable connectionErrorHandler) {
        lifecycleLock.lock();
        try {
            if (stopped) {
                throw ......
            }
            if (started) {
                throw ......
            }

            // Hold the lock until we actually start accepting connections for the case when stop is called from another
            // thread while we are in the middle here.

            Action<ConnectCompletion> connectEvent = new Action<ConnectCompletion>() {
                @Override
                public void execute(ConnectCompletion completion) {
                    RemoteConnection<Message> remoteConnection;
                    try {
                        remoteConnection = completion.create(Serializers.stateful(serializer));
                    } catch (UncheckedIOException e) {
                        connectionErrorHandler.run();
                        throw e;
                    }
                    handler.handle(new SynchronizedDispatchConnection<Message>(remoteConnection));
                }
            };

            acceptor = incomingConnector.accept(connectEvent, false);
            started = true;
            return acceptor.getAddress();
        } finally {
            lifecycleLock.unlock();
        }
    }
}

TcpIncomingConnector

  1. 创建socket channel
  2. 将accept操作存入线程池，不阻塞主线程
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
public class TcpIncomingConnector implements IncomingConnector {
 	// ......
     public ConnectionAcceptor accept(Action<ConnectCompletion> action, boolean allowRemote) {
        final ServerSocketChannel serverSocket;
        int localPort;
        try {
            serverSocket = ServerSocketChannel.open();
            serverSocket.socket().bind(new InetSocketAddress(addressFactory.getLocalBindingAddress(), 0));
            localPort = serverSocket.socket().getLocalPort();
        } catch (Exception e) {
            throw UncheckedException.throwAsUncheckedException(e);
        }

        UUID id = idGenerator.generateId();
        List<InetAddress> addresses = Collections.singletonList(addressFactory.getLocalBindingAddress());
        final Address address = new MultiChoiceAddress(id, localPort, addresses);
        LOGGER.debug("Listening on {}.", address);

        final ManagedExecutor executor = executorFactory.create("Incoming " + (allowRemote ? "remote" : "local")+ " TCP Connector on port " + localPort);
        executor.execute(new Receiver(serverSocket, action, allowRemote));

        return new ConnectionAcceptor() {
            @Override
            public Address getAddress() {
                return address;
            }

            @Override
            public void requestStop() {
                CompositeStoppable.stoppable(serverSocket).stop();
            }

            @Override
            public void stop() {
                requestStop();
                executor.stop();
            }
        };
    }

}

如下是具体的Accept操作

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
private class Receiver implements Runnable {

  	// ......

     @Override
     public void run() {
         try {
             try {
                 while (true) {
                     final SocketChannel socket = serverSocket.accept();
                     InetSocketAddress remoteSocketAddress = (InetSocketAddress) socket.socket().getRemoteSocketAddress();
                     InetAddress remoteInetAddress = remoteSocketAddress.getAddress();
                     if (!allowRemote && !addressFactory.isCommunicationAddress(remoteInetAddress)) {
                         LOGGER.error("Cannot accept connection from remote address {}.", remoteInetAddress);
                         socket.close();
                         continue;
                     }
                     LOGGER.debug("Accepted connection from {} to {}.", socket.socket().getRemoteSocketAddress(), socket.socket().getLocalSocketAddress());
                     try {
                         action.execute(new SocketConnectCompletion(socket));
                     } catch (Throwable t) {
                         socket.close();
                         throw t;
                     }
                 }
             }// catch ......
         } finally {
             CompositeStoppable.stoppable(serverSocket).stop();
         }
     }

 }

经过几次中转以后会调用到handle方法，触发后续的构建流程.

这里是后续构建过程的内容了。（暂不分析）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
public class DefaultIncomingConnectionHandler implements IncomingConnectionHandler, Stoppable {

    @Override
    public void handle(SynchronizedDispatchConnection<Message> connection) {
        // Mark the connection has being handled
        onStartHandling(connection);

        //we're spinning a thread to do work to avoid blocking the connection
        //This means that the Daemon potentially can do multiple things but we only allows a single build at a time

        workers.execute(new ConnectionWorker(connection));
    }

}

Wait

这是Daemon启动的最后一步。

当所有的初始化操作都完成以后，为了保证Daemon进程不要退出，Daemon:main线程会死循环等待。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
 daemon.stopOnExpiration(expirationStrategy, parameters.getPeriodicCheckIntervalMs());

public void stopOnExpiration(DaemonExpirationStrategy expirationStrategy, int checkIntervalMills) {
        LOGGER.debug("stopOnExpiration() called on daemon");
        scheduleExpirationChecks(expirationStrategy, checkIntervalMills);
        awaitExpiration();
}

private void awaitExpiration() {
    LOGGER.debug("awaitExpiration() called on daemon");

    DaemonStateCoordinator stateCoordinator;
    lifecycleLock.lock();
    try {
        if (this.stateCoordinator == null) {
            throw new IllegalStateException("cannot await stop on daemon as it has not been started.");
        }
        stateCoordinator = this.stateCoordinator;
    } finally {
        lifecycleLock.unlock();
    }

    stateCoordinator.awaitStop();
}

反正就是不会退出（一旦退出则表示，进程需要终结了）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
boolean awaitStop() {
        lock.lock();
        try {
            while (true) {
                try {
                    switch (state) {
                        case Idle:
                        case Busy:
                            LOGGER.debug("daemon is running. Sleeping until state changes.");
                            condition.await();
                            break;
                        case Canceled:
                            LOGGER.debug("cancel requested.");
                            cancelNow();
                            break;
                        case Broken:
                            throw new IllegalStateException("This daemon is in a broken state.");
                        case StopRequested:
                            LOGGER.debug("daemon stop has been requested. Sleeping until state changes.");
                            condition.await();
                            break;
                        case Stopped:
                            LOGGER.debug("daemon has stopped.");
                            return true;
                    }
                } catch (InterruptedException e) {
                    throw UncheckedException.throwAsUncheckedException(e);
                }
            }
        } finally {
            lock.unlock();
        }
}

总结

Daemon的启动主要是进行一些配置的初始化操作，不会触发很多逻辑

过程可以分为如下三步：

  1. Bootstrap：启动Daemon进程，设置Classloader，初始化最基本的参数
  2. Init：初始化必要的类对象，初始化服务，通过SocketChannel等待Client链接
  3. Wait：所有的初始化完毕了，为了保证Daemon进程alive，main线程死循环等待。
